A large number of connecting rod manufacturers have chosen ARP bolts as standard equipment. They're proud to advertise their products as being equipped with ARP rod bolts. And for good reason.

The weak link in a connecting rod has always been the bolt, and racers know that nobody builds a better bolt than ARP. However, it is critically important to monitor the stretch of each bolt and replace it when it has permanently elongated by .001 Inch. ARP rod bolts are superior to those from other manufacturers - especially in the area of fatigue strength.

Testing has shown ARP rod bolts to have twenty times the fatigue strength of other bolts. As such, it makes good sense to rely on ARP for optimum connecting rod service and reliability. You'll find the ARP name proudly stamped on each bolt as your assurance of quality.

8740 chrome moly is seen as a good tough steel, with adequate fatigue properties for most racing applications, only if the threads are rolled after heat-treatment, as is ARP's standard procedure. Chrome moly can be heat-treated to deliver tensile strengths between 180,000 and 200,000 psi.

Note: The grip length in undercut bolts is the distance from the head to the start of the undercut.

Details:

• Material: 8740 Chrome Moly
• Finish: Natural
• Bolt Series: Aftermarket Rod Bolt
• Kit Style: 2-Piece Pack
• Thread Size: 7/16 Inch
• UHL: 1.600 Inch
• Thread Length: 0.600 Inch
• Grip Length: 0.200 Inch
• Head Height: 0.388 Inch
• Wrench Size: 7/16 Inch
• Collar Diameter: 0.644 Inch
• Set Qty: 2
• Package Type: Skin
• Kit Type: Bolt
