Features and Benefits:

• RPM Range: 1700-4500
• Drops EGT 200-300
• Increased power we have seen 40-60hp depending on fueling and turbo.
• Duration at .050 Inch of lift 188 Intake, 220 Exhaust
• We only offer warranty on our cams if our lifters and springs are used.

Details:

• Sold As: Each
• Universal: No
• Vehicle Type: Truck
• Liter: 5.9L, 6.7L
• Fuel Type: Diesel
• Valve: 12-Valve, 24-Valve
• Material: Steel
• Duration at .050 Inch: 188 Degree Intake / 220 Degree Exhaust
• Intake Centerline: 99 Degree (12-Valve)
• RPM Range: 1,700 - 4,500 RPM

Fitment Notes:

• Fitment: 1989-2007 Dodge Ram 5.9L Cummins and 2007.5-2018 Ram 6.7L Cummins flat-tappet engines; verify piston-to-valve clearance and supporting valvetrain requirements.
• For it to be drop in on a 12v you will need no more than .018 Inch piston protrusion and at least .055 Inch valve face depth with a standard head gasket and a 99 intake centerline. On a 24v you will need no more than .018 Inch piston protrusion and at least .038 Inch valve face depth with a standard gasket. If you do not meet the minimum requirements for piston to valve clearance, don't worry, you can still run an oversize head gasket or cut valve reliefs.
• Although this is considered a drop in cam it is important to check clearances
• For the Steel version you will need at least two bushings installed in the cam tunnel, otherwise the steel could eat into the cast iron block
• We always recommend new lifters when changing a cam.

Installation Notes:

• To make sure that you have no issues during break-in, follow these few suggestions.
• Make sure that the cam has a Liberal amount of quality assembly lube applied
• Do Not let the engine start without oil pressure
• When this is a new engine, be sure to put a liberal amount of assembly lube in the oil pump and prime the oil filter
• Be sure to change the oil after you have done your break-in procedure. When the filter and oil system are already primed, engine will get oil pressure much faster than if the oil is changed at the same time.
• Disconnect the fuel system and spin the engine with the starter until oil pressure can be read or until oil is coming out of the rocker arms.
• Once oil pressure has been verified, let the engine start and run until up to operating temp
• Adjust valves then you are cleared to abuse your engine. Enjoy the added airflow
• If you need to re-torque or hot-torque the head, do so before adjusting valves. When you retorque the head, the valve lash setting, so it is important to set lash last.
• Approved oil - required. Use a 15W-40 (or 5W-40 in sub-zero conditions) with adequate zinc, phosphorus, and molybdenum. Thin or low-additive oils don't provide the shear strength a flat tappet needs.

Approved Oils:

• Valvoline Full Synthetic 15W-40
• Valvoline Synthetic Blend 15W-40
• Valvoline All-Terrain 15W-40
• Schaeffer's 15W-40
• Mobil Delvac Extreme 15W-40
• Liqui Moly Touring High Tech 15W-40
• Driven Racing Oil 15W-40
• Shell Rotella T6 Full Synthetic 15W-40
• Shell Rotella 15W-40

Applications:

• Drag strip
• Stock class pulling
